Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: Sunwe/ OEM
  • Model Number: C01
  • Type: Heat pipe solar collector
  • Application: Solar Thermal
  • Pipe Material: Evacuated Vacuum Tube

Packaging & Delivery

Packaging Details Standard export cartons
Delivery Time 7 to 10days


Type

C01-10

C01-15

C01-20

C01-25

C01-30

C01-15B

C01-30B

Number of tubes

10

15

20

25

30

15

30

Gross area (m²)

1.63

2.40

3.17

3.93

4.70

1.33

2.42

Aperture area (m²)

0.94

1.41

1.88

2.35

2.82

0.63

1.30

Absorber area (m²)

0.805

1.24

1.65

2.06

2.48

0.54

1.08

Peak power (W / Collector)

659

900

1199

1499

1799

450

900

Allowable operating pressure (bar)

6

6

6

6

6

6

6

Test pressure (bar)

10

10

10

10

10

10

10

Max. stagnation temperature

232°C

200°C

200°C

200°C

200°C

200°C

200°C

Max. operating temperature

95°C

95°C

95°C

95°C

95°C

95°C

95°C

Flow rate (l / m2h)

50-150

50-150

50-150

50-150

50-150

50-150

50-150

Absorber material

CU/AI/SS/N2 Borosilicate glass

Coating

ALN/SS-ALN/CU

Absorption coefficient

 94%

 94%

 94%

 94%

 94%

 94%

 94%

Emission coefficient

 7%

 7%

 7%

 7%

 7%

 7%

 7%

Weight (kg)

36.4

55

77

96

116

32

65

Liquid content

0.62L

0.93L

1.24L

1.55L

1.82L

0.93L

1.82L

Mounting angle

15 - 75°

15 - 75°

15 - 75°

15 - 75°

15 - 75°

15 - 75°

15 - 75°

Frame

2mm Aluminum Alloy

Heat pipe

8mm red copper

Long-term stable vacuum (Pa)

<5*10-3

<5*10-3

<5*10-3

<5*10-3

<5*10-3

<5*10-3

<5*10-3

Glass tube diameter

58mm

58mm

58mm

58mm

58mm

58mm

58mm

Vacuum tube wall thickness

1.6mm

1.6mm

1.6mm

1.6mm

1.6mm

1.6mm

1.6mm

Insulation

Compressed Rockwool

Collector width

800mm

1175mm

1550mm

1925mm

2300mm

1175mm

2300mm

Collector length

2043mm

1200mm

Manifold

38mm red copper

Tube length

1800mm

850mm

Pressure drop

<5mbar(80L/h), 12mbar (150L/h)







solar keymark EN12975 srcc OG100 certified 58/1800 evacuated vacuum tube heat pipe pressurized solar hot water collector

solar thermal collector is a solar hot water collector designed to collect heat by absorbing sunlight. The term is applied to solar hot water panels, but may also be used to denote more complex installations such as solar parabolic, solar trough and solar towers or simpler installations such as solar air heat. The more complex collectors are generally used in solar power plants where solar heat is used to generate electricity by heating water to produce steam which drives a turbine connected to an electrical generator. The simpler collectors are typically used for supplemental space heating in residential and commercial buildings. A collector is a device for converting the energy in solar radiation into a more usable or storable form. The energy in sunlight is in the form of electromagnetic radiation from the infrared (long) to the ultraviolet (short) wavelengths. The solar energy striking the Earth's surface depends on weather conditions, as well as location and orientation of the surface, but overall, it averages about 1,000 watts per square meter under clear skies with the surface directly perpendicular to the sun's rays.

The Sunwe Solar Collector or Solar Water Heater is a device that absorbs thermal energy from the sun and converts it into usable heat. The heat is normally absorbed by water, or a freeze resistant water mix, which can then be used to supplement hot water heating, space heating and even space cooling via use of an absorption chiller or dessicant cooler technology.









The working principle of solar collector is very simple.
1. Solar Absorption: Solar radiation is absorbed by the evacuated vacuum tubes and converted into heat.

2. Solar Heat Transfer: Heat pipes conduct the heat from within the solar tube up to header.
3. Solar Energy Storage: Water or water mix is circulated through the header, via intermittent pump cycling. Each time the water circulates through the header the temperatures is raised by 5-10oC / 9-18oF. Throughout the day, the water in the storage tank is gradually heated.
